PPM Grade Dual Column Inert Gas Purifier with Regeneration Heater (Removing O2 & H2O to PPM) - GPH-DHDO
PPM Grade Dual Column Inert Gas Purifier with Regeneration Heater (Removing O2 & H2O to PPM) - GPH-DHDO
GPH-DHDO connects two gas purifiers ( one for de-oxygen and another for de-humidity ) together by 1/4'' stainless steel pipe and two valves and ready to install to any MTI gas mixing system. It reduces gaseous impurities to sub-ppm levels at room temperature operation. It removes H2O, O2, CO, CO2, H2 and NMCH's to <0.1 ppm from any 99.9% purity inert gas (Nitrogen, Argon, Helium, Krypton, Neon and Xenon) and H2O, O2and CO2 from Hydrogen. What is more, it has the buit-in heater which can be heated to 300C to easily regenerate the de-oxygen and dehydration chemical in the unit for long term use.
Features:
- Input gas purity requirement: < 1000 ppm ( 99.9%)
- Output: Removal of impurities to < 0.1 ppm ( O2 ≤ 0.1ppm H2O ≤ -76 in dew point, ( Please click here to convert humidity unit )
- 304L SS (<10 Ra EP) vessel
- Easy to regenerate
- Digital temperature controller and Gas flow meter control are built in
- Purification capacity up to 80L inert gas after regeneration
- The unit should be regenerated at 250 °C ( using 5N purity gas of 95%N2+5%H2)
SPECIFICATIONS
| Power Input |
208-240V single phase 50/60Hz (110VAC version is available upon request ) Power Consumption: 500W (when heating) |
||
| Maximum Pressure Input |
0.5Mpa |
||
| Operating Temperature | Room Temperature- 300oC |
||
| Leak Rate |
< 2 x 10-9 atm cc/sec He |
||
| Temperature Controller | MTE cerified Digital temperature controller with +/- 1oC accuracy | ||
| Max. Flow rate | 400mL/minute | ||
| Gas Fittings | 1/4 Swagelok (Please order spare tube ) |
||
| Size | 445x400x190mm |
||
Application Notes |
Need to detect the oxygen content, click here for Trace Oxygen Analyzer (picture on left) or for detecting the humidity content, click here for Precision Humidity Analyzer (picture on right)
|
||
Operation Instructions |
  |
||
$899.40
Original: $2,998.00
