Magnetic De-ironing Filtration System (5L) for Battery Electrode Slurry - MSK-FT02

MSK-FT02 is a CE Certified magnetic de-ironing filtration system. It is designed for optimizing the condition of slurry before the coating process. The slurry will pass through a set of strong permanent magnetic rods and then a mesh filter to remove large particles and iron impurity. Such a system is not only able to filter out the large particles but also remove iron to improve the quality and stability of the electrode slurry.

Structure	Containers Made of Stainless Steel 304
Voltage supply	Input 110VAC - 240VAC universal power Output Power: 24Vdc via a CE, UL-certified adapter for worldwide use
Power	60W
Process Capacity	5L
Magnetic Field Strength	8000 Gs
Filter	3 mesh filters: 80, 100, 120 Optional 150, 200, 250, 325 mesh size is available upon an email request
Slurry Viscidity	<=15000CP
Humidity	0-90%RH
DE ironing Function	8000-10000 Gs
Compliance	CE Certified  CE, TUV, UL, CSA certified in power supply  Machine is safe 24VDC input which can be used without any safety certification
